Fully-auto Banknote Wrapper


Fully-auto Banknote Wrapper
Bottle neck labels, full-body bottle labels, beverage bottles, cosmetic bottles, pharmaceutical bottles, condiment bottle label shrinking
Downloads
· The machine improves the packing efficiency of the banknotes, reduces the loss of the banknote in the circulation process, and plays an important role of protection;
· Adopting industrial control system, you can print serial number, input information, QR code, etc.;
· Compatible with computer, ensuring data correspondence and facilitating information collection;
· Automatic feeding, compression, strapping, sealing and shrinking at one time completion, it is widely used in large quantities of bank currency packaging operations with high efficiency;
· Servo motor control, the advanced PLC and HMI to ensure the precise action;
· Waste film recycling system creates a clean and safe production environment.

| Model | GH-3020BM |
|---|---|
| Power | 3 kw |
| Power Supply | AC 220/380V 1/3PH 50/60HZ |
| Cross Blade Size | 204mm |
| Packing Speed | 5~8pcs/min. |
| Shrink Film | POF |
| Strapping Tape | PE |
| Strapping Tape Width | 60mm |
| Max. Packing Size L × W × H | 155 × 77 × 150mm |
| Max. Outer Dia. of film Roll | 250mm |
| Machine Size L × W × H | 1375 × 800 × 1673mm |
| Crate Size L × W × H | 1475 × 900 × 1873mm |
| G./N. Weight | 475/450kgs |
