Fully-auto Straight Feeding Sleeve Sealer & Shrink Tunnel

Small bottled goods, condiments, cosmetics bottles, multi-row small product layered packaging, medicine box

Email:info@kukoshrink.com

WhatsApp / WeChat

+86 189-1774-9969

REQUEST A QUOTE

Product Features

· Cylinder type Max. Speed: 15pcs/min.;

· Optional servo model: Mix production of different sizes;

· Film-releasing is controlled by separate motors;

· Adopted the unique linear design with compact structure, it is very suitable for some limited space and packing items without adjusting the forward direction. No length limits of items.

Technical Parameters

Model	GH-6030AZ	SF-10060E
Power	3.5 kw	30 kw
Power Supply	AC 220/380V 1/3PH 50/60HZ	AC 220/380V 3PH 50/60HZ
Max. Packing Size	400 × 600 × 380mm	Chamber Size L × W × H 2500 × 1000 × 600mm
Cross Blade Size	800mm	/
Packing Speed	0~15m/min.	0~20m/min.
Working Table Height	825 ± 25mm	825 ± 25mm
Shrink Film	PE	PE
Machine Size L × W × H	1850 × 1290 × 1800mm	3500 × 1610 × 1920mm
Crate Size L × W × H	1950 × 1390 × 2000mm	3600 × 1710 × 2120mm
G./N. Weight	560/520kgs	800/735kgs
